Telecom
Battery Pack
Battery Pack
CLN Energy Battery Pack is a high-performance lithium-ion energy storage solution designed to deliver reliable backup power for residential, commercial, and industrial applications. Engineered with advanced Battery Management System (BMS) technology, it ensures enhanced safety, longer service life, and efficient energy utilization. Its compact design, intelligent monitoring, and maintenance-free operation make it an ideal choice for modern energy storage requirements.
Available Models
48V 50Ah
48V 100Ah
Battery Pack
48V 50Ah
Reliable off-grid solar inverter for residential and small commercial backup power applications. Efficient, intelligent, and easy to install.
Technical Specifications
| Model | 48V 50Ah |
|---|---|
| NOMINAL | |
| Voltage | 48.0 VDC |
| Nominal Capacity (25°C) | 50 Ah (Capacity is measured under 0.5C / 25°C) |
| Cell Type and Chemistry | Prismatic, LFP |
| Cell Matrix | 3.2V / 50 Ah |
| ELECTRIC | |
| ENERGY | |
| Nominal Energy (25°C, 0.5C) | 2400 Wh (Capacity is measured under 0.5C / 25°C) |
| STANDARD DISCHARGE (25°C) | |
| Maximum Continuous Current | 30 A |
| Recommended Charging Current | 25 A |
| Low Voltage Cut-Off | 54 VDC |
| Charging Voltage | 53.25 VDC |
| Charge Current Limit Function | Yes |
| ENVIRONMENTAL | |
| Communication Protocol | CAN |
| LED | Green-Normal; Yellow-Alarm; Red-Fault |
| ENVIRONMENT | |
| Calendar Life (25°C) | 5 years |
| Cycle Life (0.5C, DOD 80%, 25°C) | 3500 cycles |
| Operating Temperature | 0 to +40°C (De-rating from 35°C) |
| Storage Temperature | 0 to +45°C |
| CERTIFICATION | |
| Battery Safety Standard | IEC 62619 |
| Cell Safety Standard | IEC 62133-2:2017 |
| Electrostatic Discharge (ESD) | IEC 61000-4-2 |
| Immunity Limits | N/A |
| Environmental | QM333 |
| OTHERS | |
| Pre-Charge Protection | Yes |
| Data Storage Available | Yes |
| Dimensions (W × H × D) | 450 × 442 × 133 mm |
| Mounting Design | 19 Inch Rack Based |
| Module IP Protection | IP20 |
| Weight | Approx. 32 ± 1 kg |
Battery Pack
48V 100Ah
Reliable off-grid solar inverter for residential and small commercial backup power applications. Efficient, intelligent, and easy to install.
Technical Specifications
| Model | 48V 100Ah |
|---|---|
| GENERAL CHARACTERISTICS | |
| Nominal Voltage | 48 V |
| Capacity | 100 Ah |
| No. of Cells in Series | 15 |
| No. of Cells in Parallel | 3.2V / 1Ah |
| Total No. of Cell | 15 |
| Cell Type | Prismatic |
| Chemistry | LFP |
| Maximum Cut-Off Voltage | 54.0 (±1.5) V |
| Minimum Cut-Off Voltage | 42.0 (±1.5) V |
| Charging Voltage | As per charging profile of UPS |
| Recommended Charging Current | 25 A |
| Maximum Charging Current | 50 A |
| Maximum Continuous Discharge Current | 100 A |
| Cycle Life | 3000 Cycles |
| Cell Under Voltage Protection | 2.8 V |
| Cell Under Voltage Release | 2.9 V |
| Cell Over Voltage Protection | 3.6 V |
| Cell Over Voltage Release | 3.5 V |
| PROTECTION | |
| Cell Under Voltage Protection | Yes |
| Cell Over Voltage Protection | Yes |
| Over Current Protection | Yes |
| Short Circuit Protection | Yes |
| Temperature Protection | Yes |
| TEMPERATURE | |
| Working Temperature | 0-55 °C |
| Storage Temperature | 0-45 °C |
| OTHER | |
| Module Dimension | 19 inch/5U (482 × 464 × 250 mm) |
| Color | RAL 7035 |
| Power Connector | Pole Connector |
| Communication Type | RS485 / CAN |
| MCB | 125 A |
| Weight | 45 kg Approx |
Key Features
Built for 5G & Telecom Infrastructure
Specially designed for telecom towers, BTS sites, data communication hubs, and critical backup applications.
Maximizing Energy Efficiency
With our super high-efficiency rectifiers, we significantly reduce power losses, ensuring lower energy costs and more sustainable network operations.
Streamlining Network Deployment
Our Telecom Power Solutions simplify the process of telecom site solarization, enabling quick integration of renewable energy for scalable infrastructure growth and reducing reliability on grid power.
Enhancing System Intelligence
Advanced monitoring and control tools enable real-time insights, optimizing the management of solar-powered telecom sites and efficient energy use.
Driving Future-Ready Networks
We empower telecom providers with sustainable, energy-efficient solutions like solarization and high-efficiency rectifiers, helping create resilient systems for tomorrow's connectivity.
Ensuring Uninterrupted Operations
Our all-time power solutions, including reliable backup systems powered by lithium-ion batteries, ensure consistent network performance, even during power outages.
