Telecom
Solar Module
Solar Module
CLN Energy Telecom Solar Module is a high-efficiency photovoltaic solution specifically designed to provide reliable and sustainable power for telecom infrastructure. Built to withstand harsh environmental conditions, these modules deliver consistent energy output, ensuring uninterrupted operation of telecom towers, base stations, and remote communication networks. With advanced cell technology and robust construction, CLN Energy Solar Modules offer maximum energy generation, long-term durability, and reduced operational costs.
Available Models
Solar Module
CLN483000SM
Reliable off-grid solar inverter for residential and small commercial backup power applications. Efficient, intelligent, and easy to install.
Solar Module
CLN484000SM
Reliable off-grid solar inverter for residential and small commercial backup power applications. Efficient, intelligent, and easy to install.
Technical Specifications
| Model | CLN483000RM | CLN484000RM |
|---|---|---|
| PV INPUT | ||
| INPUT VOLTAGE RANGE | 120 to 425VDC, rated 340VDC | 120 to 425VDC, rated 340VDC |
| MPPT VOLTAGE RANGE | 120 to 340 VDC | 120 to 340 VDC |
| MAX INPUT CURRENT | 17 A | 24 A |
| MPPT ACCURACY | >=0.99 @ load >= 400 W | 0.99 @ load 500 W |
| DC OUTPUT | ||
| OUTPUT VOLTAGE | -43.2 to -58VDC, rated: -54 VDC | -43.2 to -58VDC, rated: -54 VDC |
| PEAK EFFICIENCY | 98 ±0.1% | 97 ±0.1% |
| MAXIMUM CAPACITY | >96 % | >96.5 % |
| MAX OUTPUT CURRENT | 62.5 A | 81.3 A |
| CONTROL AND MONITOR | ||
| COMMUNICATION PROTOCOL | CAN | CAN |
| LED | Green-Normal; Yellow-Alarm; Red-Fault | Green-Normal; Yellow-Alarm; Red-Fault |
| ENVIRONMENT | ||
| EMC | EN55032 CE Class A; RE Class B; EN55035; IEC61000-3-2; IEC61000-3-3; IEC61000-4-5 | EN55032 CE Class A; RE Class B; EN55035; IEC61000-3-2; IEC61000-3-3; IEC61000-4-5 |
| SAFETY | EN62368-1; IEC62368-1 | EN62368-1; IEC62368-1 |
Key Features
Built for 5G & Telecom Infrastructure
Specially designed for telecom towers, BTS sites, data communication hubs, and critical backup applications.
Maximizing Energy Efficiency
With our super high-efficiency rectifiers, we significantly reduce power losses, ensuring lower energy costs and more sustainable network operations.
Streamlining Network Deployment
Our Telecom Power Solutions simplify the process of telecom site solarization, enabling quick integration of renewable energy for scalable infrastructure growth and reducing reliability on grid power.
Enhancing System Intelligence
Advanced monitoring and control tools enable real-time insights, optimizing the management of solar-powered telecom sites and efficient energy use.
Driving Future-Ready Networks
We empower telecom providers with sustainable, energy-efficient solutions like solarization and high-efficiency rectifiers, helping create resilient systems for tomorrow's connectivity.
Ensuring Uninterrupted Operations
Our all-time power solutions, including reliable backup systems powered by lithium-ion batteries, ensure consistent network performance, even during power outages.
